The display offers 3 interfaces: parallel (4-bit and 8-bit) as well as serial SPI and I²C bus. It is compatible with 3.3V systems and offers 3 different character sets: the classic one for English and Japanese, a European one and a Cyrillic one.

It can be operated with or without backlighting. ELECTRONIC ASSEMBLY offers white, amber and two-tone red/green as backlight colors. The illumination can be dimmed or switched off via an external circuit.

Test all DOG Diplays with the help of our small simulator tool.

Data sheet in German language.

The complete display family is linked here.
