COG LCD: flache Text und Grafikdisplays mit gelb/rot/blau/grün/weiß beleuchtung

EA DOGS102W-6

This display series was specially developed for
low-power hand-held applications.
For the first time it is possible to operate
a standard display at 3.3V!
The optionally available LED backlighting can also be run
with 3.3V or 5V. The preferred interface is the SPI bus.
In the mean time are a lot different character and
graphic displays available.

Display / assemble / easy / quick

Easy and quick assembly for EA DOG LCD displays

The DOG displays of ELECTRONIC ASSEMBLY which are LCD COG technology, can be assembled very easy and quickly. There is no elaborate assembly required because the displays will be just soldered to the PCB. In case of quick removal of the display, there is a way to assemble via socket connectors before you assemble the display. This is really easy. If you use a backlight you just put display and backlight together and assembly to the PCB. That's quick and easy. If the graphic display is read mainly from above, for example in front of a laborator power supply, the EA DOG graphic displays do support to become rotated by 180 degree. Some of DOG displays do provide I2C and SPI mode which is a guarantee for a fast development. Operations with the displays are easy because they do run with 3.3 V single supply. There are a lot different backlight with different colours available. That makes it easy to find the right one.
