Industrial OLED Display, bright and durable: 3.3V and SPI
OLED -40..+80°C
The world's first OLED display family with pins is available! From 2.0" to 2.9" with pins in a 2.54mm pitch not only enable quick and easy sample assembly, but also help in series production because no expensive construction is required for assembly.
All other features are also impressive:
- Top. -40..+80°C
- from freezing cold to scorching hot
- extremely wide viewing angle of over 170°
- Contrast > 1:1000
- Reaction time typ. 10µs - even at -40°C
All versions do provide SPI and I²C bus interface
| OLED displays with pins | |||||||
|---|---|---|---|---|---|---|---|
| Ordering code | Diagonal | Resolution | Dimensions | Color | Data Sheet | Shop | |
| EA OLEDS102-6GGA | 1.7" | 102x64 | 39x38x3.3 | with cover glass | yellow |  | |
| EA OLEDS102-6LGA | 39x38x2.1 | w./o. cover glass | |||||
| EA OLEDS102-6LWA | 39x38x2.1 | white w./o. cover glass | white | ||||
| EA OLEDM128-6GGA | 2.3" | 128x64 | 55x43x3.3 | with cover glass | yellow | | |
| EA OLEDM128-6LGA | 55x43x2.1 | w./o. cover glass | |||||
| EA OLEDM128-6LWA | 55x43x2.1 | white w./o. cover glass | white | ||||
| EA OLEDL128-6GGA | 2.9" | 128x64 | 68x51x3.3 | with cover glass | yellow | | |
| EA OLEDL128-6LGA | 68x51x2.1 | w./o. cover glass | |||||
| EA OLEDL128-6NGA | 68x51x1.8 | silver background | |||||
| EA OLEDL128-6LWA | 68x51x2.1 | white w./o. cover glass | white | ||||
| EA OLEDM204-GGA | 2.0" | 4x20 / 2x20 | 61x26x3.3 | with cover glasss | yellow | | |
| EA OLEDM204-LGA | 61x26x2.1 | w./o. cover glass | |||||
| EA OLEDM204-LWA | 61x26x2.1 | white w./o. cover glass | white | ||||
Character display 2x8..4x20
With it's well-known 4 bit and 8 bit parallel interface, the new OLED displays are similar to the HD44780 standard.
OLED Quick test via USB
This is how fast you have never set up a display!
With the test board EA 9781-2USB.
Connect the test board to the PC, install the USB driver and plug in the display. Immediately you will see some demo pictures on your OLED display.
Individual pictures (monochrome) can be displayed by Drag&Drop operation easyly.
The display's SPI interface is connected to some eyelets and can be used at any time with your own µC system.
Download OLED-Simulator
Data sheet for EA 9781-2USB and Simulator
Continous operation without problems
Finally, the new OLED displays from the company DISPLAY VISIONS can also be installed in industrial applications. Thanks to the new, patented OLED technology, the displays achieve a lifetime of 30,000 to 100,000 hours, depending on the color and ambient temperature.
Small graphic displays with flex cable
Whether round, whether square or extreme small with 29x9mm only, the new OLED displays from DISPLAY VISIONS play their advantage for compact handheld applications: power saving, compact and with an extreme wide operating temperature of -40..+80°C range.
Interface is serial for every 3.3V system. Thanks to the integrated controller and a lot initialization examples it is easy to display measurement, graphics and icons quick and contrasty.
OLED Graphic Displays with FPC connection | ||||||
|---|---|---|---|---|---|---|
| Ordering code | Diagonal | Resolution | Diemnsion in mm | Color | Data sheet | Shop |
| EA W064048-XALW | 0.66" | 64x48 | 18,46x18,1 | white | | |
| EA W064048-XALG | yellow | |||||
| EA W096016-XALW | 0.84" | 96x16 | 29,1x9,2 | white | | |
| EA W096016-XBLW | ||||||
| EA W128128-XRLB | 1.18" circular | 128x128 | 36,98x41,23 | blue | | |
| EA W128128-XRLG | yellow | |||||
| EA W128128-XRLW | white | |||||
| EA W128128-XALW | 1.5" | 128x128 | 33,8x36,5 | white | | |
| EA W128128-XALG | yellow | |||||
| EA W128032-XALW | 2.2" | 128x32 | 62x24 | white | | |
| EA W128032-XALG | yellow | |||||
| EA W128064-XALW | 2.42" | 128x64 | 60,5x37 | white | | |
| EA W128064-XALG | yellow | |||||
| EA W128064-XALE | green | |||||
| EA W256064-XALW | 3.12" | 256x64 | 88x27,8 | white | | |
| EA W256064-XALG | yellow | |||||
| EA W256064-XALE | green | |||||
| EA W256064-XGLG | 5.5" | 256x64 | 146x45 | yellow | | |
| OLED-Displays - Text | |||||
| Bestellbezeichnung | Zeilen x | Zeichenhöhe | Abmessungen | Farbe | Shop |
| EA W082-XLG | 2x8 | 5,5 | 58x32 | Gelb | |
| EA W162-X3LG | 2x16 | 5,5 | 80x36 | Gelb | |
| EA W162-X3LW | Weiss | | |||
| EA W162-X9LG | 2x16 | 5,5 | 85x36 | Gelb | |
| EA W162-XLG | 2x16 | 5,5 | 84x44 | Gelb | |
| EA W162-XBLG | 2x16 | 8,9 | 122x44 | Gelb | |
| EA W162-XBLW | Weiss | | |||
| EA W202-XLG | 2x20 | 5,5 | 116x37 | Gelb | |
| EA W204-XLG | 4x20 | 4,75 | 98x60 | Gelb | |
| Datenblatt oled.pdf | |||||
Englisch, Japanse European, Cyrillic
They also do provide a very fast display response time even at icy temperatures of -40°C. And the life time with such temperatures is no more a problem.
OLED with USB, RS-232 and PCAP
Brand new are our graphic capability OLED displays with USB connection and integrated touchpanel. They are good for wholesome control unit or as a display only.
In addition to some serial interfaces like RS-232, SPI and I²C there are some digital and analoge in- and outputs also. With the use of those some simple control actions with fixed display content can be realized. Currently there are 2 sizes available with 2.9" and 82x67x21mm same as 1.7" with 55x54x21mm.
EA PLUGL128-6GTC OLED with Touch, ZIFF connector for FPC
EA PLUGL128-6GTCZ OLED with Touch, ZIFF incl. screw terminals and 26-pin IDC connector for I/O's
EA PLUGS102-6GTC OLED with Touch, ZIFF connector for FPC
EA PLUGS102-6GTCZ OLED with Touch, ZIFF incl. screw terminals and 26-pin IDC connector for I/O's
Assembly is very easy with a simple put-into frontal plate and mount via self-adhesive stripes - portrait mode and landscape. Datasheet.
FAQ - Questions and Answers About OLED Displays
Questions and brief, easy-to-understand answers about OLED displays
What are the advantages of OLED displays with 2.54 mm pitch pins?
OLED displays with 2.54 mm pitch pins enable quick and easy prototyping. They are particularly advantageous in mass production, as no expensive mounting fixtures are required. These displays are available in various sizes ranging from 2.0" to 2.9". Their easy integration and low assembly effort make them an ideal choice for many applications. They also offer a long service life and are suitable for a wide temperature range.
How do you set up an OLED display using the EA 9781-2USB test board?
Setting up an OLED display using the EA 9781-2USB test board is very easy. Connect the test board to the PC and install the USB driver. Then plug in the display, and several test images will appear automatically. You can easily display your own images using drag-and-drop. This simple operation allows for quick and efficient use of the displays.
What is the lifespan of DISPLAY VISIONS' OLED displays?
DISPLAY VISIONS' OLED displays have a service life ranging from 30,000 to 100,000 hours, depending on the display color and ambient temperature. This long service life is made possible by the new, patented OLED technology. Even at extreme temperatures ranging from -40°C to +80°C, the service life remains stable. This makes them particularly suitable for industrial applications where reliability and durability are crucial.
What interfaces do the new OLED displays with touch panels offer?
The new OLED displays with touch panels offer a wide range of interfaces. In addition to the USB port, serial interfaces such as RS-232, SPI, and I²C are also available. In addition, several digital and analog inputs and outputs are onboard. This variety of interfaces enables flexible integration into various systems and applications. They can be used both as a control unit and as a display only.
What advantages do DISPLAY VISIONS' OLED displays offer in cold environments?
DISPLAY VISIONS' OLED displays are ideally suited for cold environments. They offer full functionality even at freezing temperatures of -40°C. The fast response times, typically 10 µs, are fully maintained even at low temperatures. In addition, all major character sets, including Cyrillic characters, are integrated. This makes them particularly attractive for applications in cold, Eastern European countries.
